What is the meaning of enamelled wire?

Copper paint package wire production process principle

Copper lacquer wires are coated with respective lacquer solutions, and then cured by solvent volatilization and paint film.The earliest enamel wire is oily painted wire, made from tung oil.Its paint film is abrasion resistant, and cannot be used directly to make motor coils and windings, and the cotton yarn can be added to the layer.Later, polyethylene glycol formaldehyde lacquer wire came out, and its mechanical properties were greatly improved, which can be used directly for motor windings, which is called high-strength enameled wire.

Transformer oil: It is a fractionation product of petroleum, and its main components are alkanes, cycloalkane saturated hydrocarbons, aromatic unsaturated hydrocarbons and other compounds. Commonly known as square shed oil, it is a light yellow transparent liquid with a relative density of 0.895. Freezing point <-45¡æ.
Transformer oil is a kind of mineral oil obtained by distillation and refining from natural petroleum. It is a liquid natural hydrocarbon that is pure and stable, with low viscosity, good insulation, and good cooling by acid-base refining treatment of the lubricating oil fraction in petroleum. Mixture of compounds. Commonly known as square shed oil, light yellow transparent liquid.

The structure of enameled wire is very simple, consisting of conductor and insulating layer. Because of its high dielectric strength, small footprint and good heat dissipation, it is widely used as a coil winding in motors and transformers.

Use a hydrogen-oxygen flame welding machine to weld the coil lead wires of electronic devices such as motors, motors, and transformers.

working principle:
Water is composed of hydrogen and oxygen. In a specific electrolytic cell, water can be decomposed into hydrogen ions and hydroxide ions. The hydrogen ions move to the cathode to generate hydrogen gas, and the hydroxide ions move to the anode to generate oxygen. Hydrogen is a fuel. Oxygen can be used to support combustion. It can be ignited by a specific hydrogen-oxygen flame gun to form a hydrogen-oxygen flame, which can quickly weld the enameled wire.

Poor soldering is mainly manifested in that the paint film after soldering will not melt off after the soldering, which causes the phenomenon of poor soldering.

1. Different materials: structure and composition are different
2. Different performance: Since the three-layer insulated wire cannot be directly welded, it needs to be stripped first, and the cost is higher, and it will be replaced by FIW; the insulation level is different, and the three-layer insulated wire can be produced with a temperature resistance of 200 degrees
3. Can be different in color, etc.

Paper Wrapped Aluminum wire Production Process

One step :
Take the pure aluminum material drawing into the aluminium rod wire;

Two step :
Through the extrusion production line, take the aluminum rod wire into extruding and coarse drawing operation, then becoming the requirement specification of Bare aluminium wire;

Three step :
Take up the Bare aluminum wire conductor, and inspection the bare wire coil products;

Four step :
Annealing the bare aluminum wire, and placed neatly, ready to production;

Five step :
Doing the digital dividing and cutting paper process and finished;
Pay-off the wire coil products, ready to paper covering production;

Six step :
Taking into straightening and tension lenvelling operation, ready to paper winding;

Seven step :
Taking into the paper winding operation, and then for inspecion;

Eight step :
Pulling the finished paper-covered wire, and then for take-up the wire coil , ready to packing.

Certification: SGS,UL
Size: 0.2mm-8.0mm
Delivery time: 10-30days
Thermal Class: 130-220C
Conductor Material: Copper Clad Aluminum

Winding wires used in electrical equipment are usually called magnetic wires. In other words, “magnetic wires are used to exchange electrical energy and magnetic energy.” Magnetic wire is roughly divided into enameled wire (insulation coated) and coated wire (fiber/film insulation) and their combinations. The two types of magnetic wires and their performance are very different. ASTM (American Society for Testing and Materials) B193, no more than 0.017241 ohm (square millimeter/meter), the film or coating should meet the latest version of ANSI, ASTM or NEMA applicable standards, and modify the specified resin. The modified resin is Chemically changed resin, or containing one or more additives to retain the basic chemical characteristics of the original resin to enhance certain performance or application characteristics, the coated conductor needs to meet all the required test requirements of the appropriate NEMA standard (UL certification project) .

Enameled wire motors, electrical appliances, home appliances, communications, electronic information, instrumentation, power tools, automobiles and other industries provide supporting basic material industries. They are the main and key raw materials for electromagnetic windings of motors and electronic instruments. The rapid development of electronic products, etc., has brought a broader application field and market to enameled wires, but at the same time, higher requirements have been put forward for enameled wires, and enameled wires have continued to develop towards a high level and high quality.

enameled aluminum wire is composed of aluminum conductor and insulation materials, which is insulated with a thin film or coating and creates a magnetic field when the wire is would in a coil and power is applied. Aluminum Conductor is main type of enameled wire.

AWG magnet wire is also called enamelled manganin wire which is composed of copper or aluminum conductor with insulation materials, such as PE, EI, UE, etc. The enameled wire have different performance according to chemical performance, heat resistance and others.

The Flat magnet wire size:
155 modified polyester enameled rectangle wire: a: 1.00-5.00;b: 2.00-16.00
180 polyester imied enameled rectangle wire: a: 1.00-5.00;b: 2.00-16.00
220 polyester imied enameled rectangle wire: a: 1.00-5.00;b: 2.00-16.00
200 polyester imeid/polyamide-imide enameled rectangle wire: a: 1.00-5.00;b: 2.00-16.00

The round enameled wire size
155 modified polyester enameled aluminum round wire: 0.25mm – 2mm
200 polyester imeid/polyamide-imide enameled round copper wire:0.016-7mm

The enamel wire is a wire having an insulating layer, which is a transformation of electromagnetic energy in a winding form, also known as a winding wire.

Flat enameled wire is a type of enameled wire. It is a winding wire made of oxygen-free copper rods or electrical aluminum rods that are drawn, extruded or rolled by a certain specification die, and then coated with insulating paint for many times. The thickness is from 0.025mm To 2mm, the width is generally less than 5mm, and its aspect ratio ranges from 2:1 to 50:1. Flat enameled wire has a wide range of uses, especially in the windings of various electrical equipment such as telecommunication equipment, transformers, motors and generators.

The wire drawing metal processing technology can form fine lines on the surface of the metal material, which makes the metal more textured, and is used as a decoration by users and is well-loved. In the production process, the drawing lubricating fluid is indispensable in the drawing metal processing technology. It is widely used in the lubrication of the middle drawing, small drawing and micro drawing of enameled copper wire. So how to choose this kind of drawing fluid?

In the long-term thermal aging test, three or more temperature points are usually selected for accelerated aging, commonly known as “three-point aging”.

The samples for the aging test are stranded enameled wire pairs. The production of the stranded pairs should meet the requirements of ASTM D2307 or NEMA 1000 standards, including the weight to be applied when making the stranded pairs, the number of twisted turns, the effective length of the stranded area, and The length of the two ends of the twisted pair, etc. When making a twisted pair, the required force and the number of twist turns will vary depending on the diameter of the wire. The effective length of the stranded area has nothing to do with the wire diameter, the effective length is 121¡À6 mm, and the two ends are at least 50 mm long. At least 10 twisted pairs per temperature point and mounted on twisted pair racks for high temperature aging test.

Enameled wire is widely used in our production and life. The paint it uses is a kind of paint that can produce a good insulating layer between the wires in the winding.
Enameled wire is made on the basis of copper wire. Simply put, enameled wire is a layer of insulator on the copper wire, usually plastic. Enameled wire paint is a kind of outer layer of bare copper wire, alloy wire and glass wire covered wire of various wire diameters to improve and stabilize the performance of enameled wire. It has high mechanical strength, resistance to Freon refrigerant, good compatibility with impregnating paint, and can meet the requirements of heat resistance, impact resistance, oil resistance, etc.

List 5 type of enameled wire characteristics
Acetal enameled wire
Polyurethane enameled wire
Polyester and modified polyester enameled wire
Polyesterimide/polyamide imide composite enameled wire
Polyesterimide/polyamide composite enameled wire

Fiberglass Covered Insulated rectangular aluminum wire is in accordance with customer requirements in aluminum conductor uniform whole winding package 1-2 layers of alkali-free fiberglass, with the necessary temperature resistance index and compatible adhesive paint dipping and baking process, glass fiber and conductor between bonded into a whole.

The samples for the dielectric strength test are also twisted pairs, and the number is 5 pairs. During the test, the voltage was applied at a boosting rate of 500V/S until breakdown, and the voltage at the time of breakdown was recorded. The requirements for dielectric strength in the NEMA MW1000 standard will vary according to different wire diameters, different paint film thicknesses, and different enameled wire types.

According to SMM survey data, the operating rate of enameled wire in September was 71.32%, down 8.28% year-on-year, down 1.82% month-on-month, and 1.65% lower than the expected 72.97%. Among them, the operating rate of large enterprises was 71.56%, down 0.69% from the previous month; medium-sized enterprises fell by 4.06% to 71.50%, and small enterprises fell by 0.55% to 60.83%.

The difference between enameled aluminum wire and enameled copper wire of vibration motor: the resistivity of copper wire is 0.017, and the resistivity of aluminum wire is 0.028. The cross-sectional ratio of copper wire and aluminum wire interchange is 0.79:1, and six square copper wires are equivalent to ten square aluminum wires. The diameter of the aluminum wire is thicker than that of the copper wire, and the same aluminum wire of the stator slot will not fit.

High Temperature Aluminum Magnet Wire (Anodized aluminium wire) belongs to the special electromagnetic wire and the insulation layer is the aluminum oxide . Because of no thermal aging phenomenon, it can be used as insulation level of class 220.
The insulation layer of such product is thin, high temperature resistance and insulation performance stability,which is the best choice for low voltage winding wires with producing high temperature, poor environment, heat dissipation difficulty and so on.
It can widely be used in electromagnetic industries at home and abroad.

Enameled Copper Coating Aluminum Wire refers to the wire with aluminium core as the main body and a certain proportion of copper coating on it. It can be used as conductor of coaxial cable and conductor of wire and cable in electrical equipment.Polyurethane enameled wire; thermal grade 130, 155, 180, 200. It is characterized by direct welding, good high frequency resistance, easy coloring and good moisture resistance.

Wire enamel insulating varnish is a kind of paint that can produce a good insulation layer between the wires in the winding. It is mainly used for the outer layer of bare copper wire, alloy wire and glass wire covered wire of various wire diameters to improve and stabilize the performance of enameled wire.

1060 Transformer Aluminum Strip Product Description:
060 transformer aluminum belt is a special purpose aluminum belt product produced for transformers. It uses high-purity aluminum substrate and aluminum deep-processed products formed by slitting aluminum coils with an aluminum content of more than 99.60%. The raw material of transformer aluminum strip is high-purity aluminum, which is rolled into thin sheet aluminum coils of different thicknesses and widths by a cold rolling mill, and then longitudinally slitted into aluminum strips of different widths by a slitting machine according to the application. It is an important raw material in industry. The main processing equipment of 1060 transformer aluminum strip is slitting unit, which can be divided into required length and width according to needs. Usually the transformer aluminum strip is slit according to the actual needs of the user, which can reduce waste, reduce processing procedures (without cutting), and save raw material costs.

British Standard Wire Gauge (often abbreviated to Standard Wire Gauge or SWG) is a unit for denoting wire size given by BS 3737:1964 (now withdrawn). It is also known as the Imperial Wire Gauge or British Standard Gauge. Use of SWG sizes has fallen greatly in popularity, but they are still used as a measure of thickness in guitar strings and some electrical wire. Cross sectional area in square millimetres is now the more usual size measurement for wires used in electrical installation cables. The current British Standard for metallic materials such as wire and sheet is BS 6722:1986, which is a solely metric standard.

Kraft Insulated Copper Stranded Paper Covered Wire refers to the insulation layer of the wire wrapped with cable paper. The paper covered wire insulation has at least 3 layers to wrap the paper tape. When it exceeds 3 feet, the innermost and outermost layers should be covered and wrapped, and the rest can be wrapped around with a gap of no more than 2mm. When the width of the paper tape is 9.5 When mm and above, the gap should not exceed 3mm.

According to the characteristics and uses of insulation, winding wires can be divided into four categories: enameled wires, wrapped wires, special winding wires, and inorganic composite winding wires.

The enameled wire paint coats up to 30 layers of copper and aluminum wires to provide electrical insulation and help avoid short circuits in the coil. Such enameled wire paint must also have excellent chemical resistance and high temperature resistance, must have excellent adhesion with copper or aluminum wires, and also have excellent mechanical stability.
In some cases, such as for motors driven by frequency converters, a suitable insulation layer should be able to resist partial discharges that may cause short circuits and malfunctions in the engine.
