Correspondence table of enameled wire diameter and resistance value
The resistivity of the copper wire ρ= 0.0172, the aluminum wire ρ = 0.0283, the wire resistance calculation formula:
R=ρ×L/S
(L = wire length, unit: meter, S = wire cross section, unit: mm^2)

The current mainly passes along the copper-clad aluminum wire on the surface of the wire, which is called the skin effect. The higher the frequency, the more obvious it is. The copper-clad aluminum wire uses this feature to save material. But its resistivity is slightly higher than that of pure copper wire, and the resistivity is also different with the thickness of the copper clad.

Although the quality of enameled wire depends to a large extent on the quality of raw materials such as paint and wires and the objective conditions of machinery and equipment, if you do not take a series of problems such as baking, annealing, and speed, and understand their interrelationships. , Do not master the operation technology, do not seriously do the touring work, stop and tidy up the work, do not do well in the process and hygiene, even if the objective conditions are good, it will not be able to produce high-quality enameled wire. Therefore, the decisive factor for good enameled wire is people’s sense of responsibility for work.

To weld the lead aluminum enameled wire, it is necessary to remove the paint (there are very few household electric fans with very low requirements, and the ballast manufacturer does not remove the paint). The paint removal methods are listed below.
(1) It can be scraped with a blade,
(2) It can be peeled with a centrifugal knife,
(3) The paint can also be rubbed off with a grinding wheel,
(4) Of course paint remover is also available,
(5) You can also use high-temperature tin to burn the paint,
(6) Some people burn with fire
(7) Of course you can also use paint remover to remove paint

Enameled Aluminum Wire connects Enameled Copper Wire with the short service life according to the test. The contact part of the enameled copper wire and the enameled aluminum wire will accelerate the oxidation of the aluminum wire.

Polyimide Film Covered Aluminum Wire Production Process

One step :
Take the pure aluminum material drawing into the aluminium rod wire;
Two step :
Through the extrusion production line, take the aluminum rod wire into extruding and coarse drawing operation, then becoming the requirement specification of Bare aluminium wire;

Three step :
Take up the Bare aluminum wire conductor, and inspection the bare wire coil products;

Four step :
After annealing the alumium wire coil , cleaning and pay-off the wire coil, ready to next operation;

Five step :
Taking into straightening and Tension levelling operation, varnish treat the surface of wire, and then for the glass fiber covered;

Six step :
And then for baking the fiberglass wire , pulling the finished wire, and take-up the fiberglass wire products.

Product Name:Oil Immersed Transformer Winding Wire
Type: round or rectangular wire
Features: Telephone paper, cable wire or 500KV transformer turn-to-turn insulation paper is used for insulation. After dipping.
Conductor Material:Aluminum or Copper
Application:used for Oil Immersed Transformer, transformer coils
Certificate:UL,RoHS
Thermal Class:105¡æ

Poor soldering is mainly manifested in that the paint film after soldering will not melt off after the soldering, which causes the phenomenon of poor soldering.

Features of Aluminum Enameled Electric Wire 1.5mm For Moxico
1) Excellent bending performance
2) High flexibility of enamel
3) Good wear resistance
4) High mechanical properties
5) Higher thermal performance
6) Good resistance to refrigerants and Freon
7) Suitable for windings subjected to continuous high temperature and mechanical stress
8) Good chemical resistance
9) Excellent mechanical and chemical properties

We are factory specializing in the manufacture and export of enameled Coil Aluminum winding wire (EAL wire, Aluminum winding wire ) for more than three years. We have profuse designs with series quality grade, and expressly, our price is very competitive because we are manufactory, we are the source.

3M paper covered aluminium wire feature :
* High dielectric strength/Excellent therm alstability/Wrapped tightly;
* Paper covered Aluminum wire is a special kind of magnet wires. Its conductors is electrical round aluminum rods which squeeze
and draw by the certain size of mold. And its insulations is special material;
* Our 3M paper covered aluminum wire uses two layers or several layers as the insulation layer;
* The wrapping direction of paper is same. And every layer paper twines conductors continually and compactly without wrinkles;
* Uses for oil-immersed transformers, reactors and other windings;

Enameled wire coating is mainly used for coating and insulation of enameled wire cores. Since the wire will be subjected to heat, chemical and various mechanical forces in the process of winding coils and embedding wires, the enameled wire paint is required to have good coating properties (that is, uniform coating), and strong paint film adhesion.

Advantages of oxide film wire
1. The oxide film is not sealed by insulating paint, and the temperature resistance can reach 250¡æ. The heat resistance of the oxide film sealed with insulating paint depends on the temperature index of the insulating paint;
2. High slot full rate, light weight and good radiation resistance.

Round Enameled Wire can be designed in 0.016-7mm, why choose the round enameled wire used for your electrical equipment and other electric field. List the 4 characteristics of enameled copper wire.

The main advantages of fiberglass covered wire are:
1. The quality factor Q value is large;
2. Because it is twisted by multiple enameled wire bundles, it has good flexibility and can reduce the skin effect;
3. Because it is composed of polyurethane enameled wire, the dielectric loss angle is small, and it has direct solderability.
The disadvantage is: poor moisture resistance.

Wire Enamel Coating is important used for enameled wire or magnet wire, the application is used for transformer winding coils and motor coils forming insulation to prevent short circuits.

Electrical wiring to be run in conduit comes in individual strands, encased in insulation to protect the wire and insulate it from other wires and the conduit. Wires come in ither solid or stranded, depending on the wire size. Bare conductors are available for ground wires only. The insulation is made to take on some rather extreme conditions. Heat-, oil-, gasoline- and water-resistant coatings are all available to help your Insulated electric wire survive.

Enameled wire is a main type of magnet winding wire. It is composed of a conductor and an insulating layer. After the bare wire is softened by annealing, it is painted and baked many times. However, it is not easy to produce products that not only meet the requirements of the standard, but also meet the requirements of customers. It is affected by the quality of raw materials, process parameters, production equipment, environment and other factors. Therefore, the quality characteristics of various enameled wires are different, but they all have Mechanical properties, chemical properties, electrical properties, and thermal properties

1. Mechanical functions: including elongation, rebound angle, softness and adhesion, paint scraping, tensile strength and other items.
(1) Elongation reflects the plastic degeneration of the material and is used to check the ductility of the enameled wire.
(2) The rebound angle, the softness reflects the elastic deformation of the material, and is used to check the softness of the enameled wire.
¢ÇThe durability of the paint film includes winding and stretching, that is, the promised tensile deformation of the paint film without cracking when the conductor is stretched and deformed.
(4) The adhesion of the paint film includes snap-off and peeling. First, check the adhesion of the paint film to the conductor.
(5) The scratch resistance test of the paint film reflects the strength of the paint film against mechanical scratches.

Aluminium Alloy Wires are made from a wide range of aluminum alloys, depending on the customer requirements. Aluminium wires are sold to manufacturers of eyelets, rivets, nails, screws and other various products. Bare Aluminium Wire is used for Cables, Junctions, Rivets, Hangers, Clips and other household Items.

The temperature resistance index of Class 155 Reasonable Price Glass Fiber Covered Aluminum Round Wire has three grades: 130, 155, and 180, and the insulation thickness generally has four grades of 20, 30, 40, and 50. This product is widely used in windings of transformers, electromagnets, welding machines or other similar electrical equipment products. Electrician bare aluminum wire produced by extrusion process is the most ideal material for producing glass fiber coated aluminum wire.

Aluminum bare magnet wire (Anodized Bare Aluminium wire) belongs to the special electromagnetic wire and the insulation layer is the aluminum oxide .Because of no thermal aging phenomenon, it can be used as insulation level of class 220.
The insulation layer of such product is thin, high temperature resistance and insulation performance stability,which is the best choice for low voltage winding wires with producing high temperature, poor environment, heat dissipation difficulty and so on. It can widely be used in electromagnetic industries at home and abroad.

Glass-fiber covered aluminum magnet wire used to have weak coating strength (abrasion resistance, shock resistance, and flexibility). However, that disadvantage has been significantly improved recently by refining material selection and manufacturing methods. The demand for glass-fiber covered aluminum magnet wire is increasing as the wires have excellent uniformity and electrical properties under high temperatures and humidity.

Application of enamel coated magnet wire
Wire for winding used in electrical equipment is generally called magnet wire. Simplyput,”enamel coated magnet wire is used for interchanging electrical energy with magnetic energy”.Magnet wires are broadly divided into enamelled wire (coating insulation), coveredconductor wire (fiber/film insulation), and combinations thereof.

7 type of enameled wire in accordance with insulation materials, list the thermal class, advatanges and application per type of enameled wire. Enameled wire types also can be divided into copper magnet wire and aluminum wire in accordance with conductor.

Paper covered wire by Electrical Aluminium Pole extrusion die by a certain size or drawn wire after annealing, and then in the aluminum conductor wrapped more than two or two insulating paper (including paper, telephone, cable paper, high voltage cable paper, turn insulation paper) of the winding wire, suitable for oil-immersed transformers and other electrical winding with a similar wire. Produced by the extrusion process electrical bare aluminum wire is wrapped production of the cable wire is the best material.

Round Enameled Wire is used for transformer coil winding and motor winding, also called electric motor winding wire. And to Measure The Specifications Of Round Enameled Wire is important, include the conductor diameter and insulation diameter.

Thermal Class: 130-220C
Conductor Material: Copper
Standard: IEC,NEMA,GB,JIS
Delivery time: 7-30 Days
Brand Name: LP Magnet Wire
Insulation: PEW, PIW, EIW, AIW, EI/AIW

Best Selling 155 Class Enamelled Copper/Aluminum Winding Wire includes copper wire and aluminum wire used for transformers, inductors, motors, generators, dry type transformer, Cast Resin Transformers. Thermal Class:Class 155, popular used for low voltage dry type transformers.

Wire for winding used in electrical equipment is generally called magnet wire. Simply put, ¡°Magnet wire is used for interchanging electrical energy with magnetic energy¡±.
Magnet wires are broadly divided into enamelled wire (coating insulation), covered conductor wire (fiber/film insulation), other specially formulated wire, and combinations thereof.

Telephone cable is usually thought of only as a communication medium operating at a normal 48 Vdc level. But telephone cable is regularly used by telephone operating companies to supply power to remote telephony equipment such as: PCM (Pulse Code Modulation) repeaters, FDM (Frequency Division Modulation) repeaters, telegraph and various types of control circuits. The normal talk battery voltage is regularly exceeded in the case of long subscriber loops utilizing loop extenders and on dial long line circuits which operate in the 70 to 100 Vdc range. For these applications, the referenced devices are generally current limited to approximately 150 milliamps. In all such cases, normal telephone industry practice usually limits pair-toground applied voltage to 150 Vdc, and pair-to-pair voltage is usually limited to 300 Vdc.
